C-Line Roller Garage Door Opener

C-Line

Home / PRODUCTS / Roller door opener
C-Line Roller Garage Door Opener

Black shell, designed to deliver a slim profile, reliability, security and convenience. One row type control panel with silicone keys and elegant white dust cover.

PARAMETER

Power600N1000N
Input voltage230V/110V,50-60Hz
Standby power2.2W
Motor type24V D.C. permanent magnet
Opening speed160mm/second
Max. door area10m²15m²
Opening / Closing limits travel7 turns
Max. door height  5000mm
Side room requirement                 85mm
Receiver / Transmitter frequency   433.92MHz / 868.35MHz
Coding system                  Rolling code technology
Transmitter capacity (x 4-button registers)                50

Features

*L.E.D off delay time setting

*Soft stop function during operation

*Automatic closing&time setting




RECOMMENDED ACCESSORIES



REMOTE RC07                RubberButton,Comfortable feel

Stylish design

4 buttons

Rolling code technology Power supply 3V Frequency 433.92 MHz





SD PROTECTION 01

Wireless Wicket-door ProtectorIncluding:

Water-Proof Signal Receiver * 1

Wireles Sensor * 1

Magnetic Box * 1

Range(nominal): 50 meters






Flash light


Working voltage: 24V DC/AC & 80V-250V AC

Flicker frequency: 1 Hz

IP level: IP 64

Working temperature: -20℃ ~ +60℃

Inner antenna to extend the effective distance of controller
